Induction Stove or cook tops working principle of operation. Parts of Induction stove 1. Magnetic copper coil 2. Ceramic plate 3.cooling fan 4.Ferrites 5.Insulated Gate Bipolar Transistor 6.Central Processing Unit 7.Wiring to CPU & Burners 8.Cookware Sensors 9.Inductors (Burners) 10Control Panel.....ect. Working Principle Induction cooking heats a cooking vessel electrically by magnetic induction, instead of by radiation or thermal conduction from an electrical heating element, or from a flame. Because inductive heating directly heats the vessel, very rapid increases in temperature can be achieved, and changes in heat settings are instantaneous. In an induction cooktop a coil of copper wire is placed under the cooking pot and an alternating electric current is passed through it. The resulting oscillating magnetic field induces an electrical current in the pot. This large eddy current flowing through the resistance of the pot results in resistive heating. For nearly all models of induction cooktops, a cooking vessel must be made of, or contain, a ferrous metal such as cast iron or some stainless steels. The iron in the pot concentrates the current to produce heat in the metal. If the metal is too thin, or does not provide enough resistance to current flow, heating will not be effective. Most induction tops will not heat copper or aluminum vessels because the magnetic field cannot produce a concentrated current; "all metal" induction tops use much higher frequencies to overcome that effect. Any vessel can be used if placed on a suitable metal disk which functions as a conventional hotplate. Induction cooking is quite efficient, which means it puts less waste heat into the kitchen, can be quickly turned off, and has safety advantages compared to gas stoves. Cooktops are also usually easy to clean, because the cooktop itself does not get very hot. Thank You for watching...
Induction cook tops working in tamil - YouTube |
| 207 Likes | 207 Dislikes |
| 5,397 views views | 60,810 followers |
| Education | Upload TimePublished on 6 Jan 2019 |
